Items

Specification

MB500B

MB500T

Eyepiece

WF 1 0× -18 mm

○

○

WF 1 0× -20mm

●

●

WF1 6× -13mm

○

○

WF 1 0× -18 mm (With Pointer)

○

○

WF 1 0× -18 mm (Reticule 0.1mm)

○

○

Infinity Plan Objectives

IOS 4 × /0.10

●

●

IOS 10 × /0.25

●

●

IOS 20 × /0.40(S)

●

●

IOS 40 × /0.66 (S)

●

●

IOS 100 × /1.25 (Oil) (S)

●

●

Seidentopf Binocular Head
（ For Infinity System ）

Inclined 30 ° ,Rotatable 360°,
Interpupilary Distance：50-75mm

●

Seidentopf Trinocular Head

Inclined 30 ° ,Rotatable 360°,
Interpupilary Distance:50-75mm,
Light Distribution: 0:100

　
○

Seidentopf Trinocular Head
（ For Infinity System ）

Inclined 30 ° ,Rotatable 360°,
Interpupilary Distance:50-75mm,
Light Distribution: 0:100

○

●

Nosepiece

Quadplex

○

○

Quintuple

●

●

Mechanical Stage
（ Size: 190m m× 140mm ）

Travel: 78mm × 55mm,
Coaxial Coarse and Fine Focusing
Knobs

●

●

Condenser

Abbe N.A. 1.25 (Iris Diaphragm)

●

●

Koehler Illumination System

6V/20W Halogen Lamp(G4)

●

●

6V/30W Halogen Lamp(G4)

○

○

LED Illumination System

○

○

C-mount

0.3 ×

○

○

0.5 ×

○

○

1 ×

○

○

Adaptor For Digital Camera

○

○

Field Diaphragm

●

●

Filter

Blue

●

●

Green

○

○

Amber

○

○

Fluorescence, Phase Contrast, Dark field, Polarize And Incident Accessories Are Optional.
