Specification:

MB320M

MB320B

MB320T

Optical System

Finite Optical System

●

●

●

Viewing Head

Monocular Head, Inclined at 30º ，360º Rotatable

●

Seidentopf Binocular Viewing Head, Inclined at 30º ，360ºRotatable

●

Seidentopf Trinocular Head，Inclined at 30º ，360ºRotatable

●

Eyepiece

Wide Field Eyepiece WF10X/18mm

●

●

●

Wide Field Eyepiece WF16X/13mm

○

○

○

Wide Field Eyepiece WF20X/11mm

○

○

○

Objective

Finite 195 Series Achromatic Objectives
4X 10X 40Xs 100Xs(oil)

●

●

●

Finite Plan Achromatic CF Objectives
4X 10X 40Xs 100Xs(oil)

○

○

○

Nosepiece

Quadruple Nosepiece

●

●

●

Condenser

Abbe Condenser NA1.25 with Diaphragm，Filter

●

●

●

Focusing System

Coaxial Coarse and Fine Adjustment,
Fine Division 0.002mm, Coarse Stroke36mm

●

●

●

Stage

Double Layer Mechanical Stage 115x125mm

●

●

●

Illumination

3W/LED Adjustment，rechargeable battery

●

●

●
